Mini ITX 6.7” X 6.7” Industrial Motherboards H-SKLU01
Based on 6/7/8th generation Intel Core processor platform
1x SO-DIMM DDR3 expansion memory slot, supports up to 8GB
1 M.2 KEY-E 2230 interface, expand Wi-Fi + BT module
1 M.2 KEY-B interface, expand 4G/5G module
1 M.2 KEY-M interface, expand NVME/SATA adaptive storage module
Support HD/VGA/ED/LVDS display output
2 Gigabit Ethernet
Maximum expansion of 10 USB, 6 COM
Send Inquiry
Product Details ofMini ITX 6.7” X 6.7” Industrial Motherboards H-SKLU01
Based on 6th/7th/8th generation Intel Core processor platform
1 SO-DIMM DDR3 expansion memory slot, support up to 8GB
1 M.2 KEY-E 2230 , expand Wi-Fi + BT module
1 M.2 KEY-B , expand 4G/5G module
1 M.2 KEY-M , expand NVME/SATA adaptive storage module
Support HD/VGA/ED/LVDS display output
2 Gigabit Ethernet
Maximum expansion of 10 USB, 6 COM
Support M.2 KEY-E WiFi/Bluetooth and other expansions M.2 Key-B 4G/5G M.2 Key M + SATA3.0 dual storage, dual EDP, LVDS, HDM, VGA multiple displays, with high reliability and stability, meeting the requirements of self-service, retail, all-in-one, industrial control and other working environments
H-SKLU01
| CPU | Intel® 6th/7th/8th CoreTM i3/i5/i7 or Celeron processor |
| Chipset | Intel SOC integrated |
| Display controller | Intel CPU integrated UHD |
| Display Port | 1*VGA: Max resolution up to 1920*1080@60Hz 1*HD: Max resolution up to 4096*2160@24Hz 1*LVDS/eDP: LVDS,Dual Channel 24 bit, Max resolution up to 1920*1200@60Hz 1*eDP, Max resolution up to 1920*1200@60Hz Choose one of VGA and EDP2 colay, choose one of LVDS and Edp1 colay |
| Memory | 1xDDR4 SODIMM memory slot, up to 8GB |
| Storage | 1*SATA3.0, 1*M.2 2242/2280 supports SSD with SATA/NVME |
| Audio | Rear IO supports Mic-in, Line-out, supports chassis front panel audio, supports dual-channel 2W/8Ω, 3W/4Ω power output |
| Network | 2xRJ45 Gigabit Ethernet port RTL8111H (LAN2 and USB3.0 colay) |
| USB | Rear IO: 4x USB3.0 (double-layer USB 3.0 Type-A) Onboard: 3 2*5N9Pin Headers, 3*USB2.0 expansion (one of which colays with rear IO USB2_LAN2) |
| Parallel port/I²C/ | 1 LPT parallel port pin |
| Serial port | 6 RS232 serial ports COM2&COM3 support Pin9 5/12V power supply |
| Expansion bus | 1 M.2 KEY-E (PCIE X1+USB2.0 signal) 1 M.2 KEY-B (PCIE X1+USB3.0 signal) |
| Other ports | 1 JPS/2, 1*JGPIO, 1*Debug, 1*JAT/ATX |
| Temperature & Humidity | Storage temperature and humidity: -20~75℃ 10%~90%, non-condensing Working temperature and humidity: 0~60℃ 10%~90%, non-condensing |
| Operating system | Windows 10/11, Linux |
| BIOS | AMI UEFI BIOS |
| Special functions | support watchdog, diskless boot, network wake-up, power on, timed boot |
| Power supply | DC 12V |
| PCB size | 170mm*170mm(L*W) |
| Model | CPU | LVDS | EDP | HD | VGA | LAN | USB | COM | M.2 | MINI-PCIE | |
| 3.0 | 2.0 | ||||||||||
| Hm-SKLUD11-VL | 3-6100U I7-6200U I7-6500U I3-7100U I5-7200U 5-7500U I3-8130U I5-8250U I7-8550U |
1
|
/ | 1 | 1 | 1 | 4 | 4 | 1 | 2 | / |
| Hm-SKLUD12-2E |
/
|
2 |
1
|
/ | 1 | 4 | 4 | 1 | 2 | / | |
| Hm-SKLUD16-2E |
/
|
2 | 1 | / | 1 | 4 | 4 | 1 | 2 | / | |
| Hm-SKLUD12-VL | 1 | / | 1 | 1 | 1 | 4 | 4 | 1 | 2 | / | |
| Hm-SKLUD16-VL |
1
|
/ | 1 | 1 | 1 | 4 | 4 | 1 | 2 | / | |
| Hm-KBLUD12-2E | / | 2 | 1 | / | 1 | 4 | 4 | 1 | 2 | / | |
| Hm-KBLUD16-VL |
1
|
/ | 1 | 1 | 1 | 4 | 4 | 1 | 2 | / | |
| Hm-SKLUD26-VL | 1 | / | / | 1 | 2 | 2 | 6 | 6 | 3 | / | |
