7th Gen Core I5 I7 Industrial PC PCI Slot
◇ 1xDDR4 Max. Support 16GB RAM Slot
◇ Support WIFI/3G/4G Optional（Choose one from three）
◇ 1*PCIE X4 + 1*PCIE X1，Built-in 1*USB2.0
◇ 2*PCI（32bit），Built-in 1*USB2.0
◇ OS：
Send Inquiry
Product Details of7th Gen Core I5 I7 Industrial PC PCI Slot
Corrected Version:
The IBOX-701Plus features one DDR4-1866/2133 SO-DIMM slot supporting up to 16 GB of memory. For easy cabling and maintenance, the IBOX-701Plus-rated embedded system offers a wide range of front-accessible I/O interfaces, including:
- 2 × USB 3.0
- 2 × USB 2.0
- 2 × Indicator lights
- 1 × Power switch
Rear I/O interfaces include:
- 2 × USB 3.0
- 2 × Intel 1000M LAN ports
- 1 × VGA
- 1 × 3-pin Phoenix power connector
- 1 × Clear CMOS button
Standard 4 × COM ports (expandable to 6 COM ports; COM1 and COM2 support RS232/422/485 optional modes)
The compact industrial PC also provides Expansion Port,1*MINI PCIE Slot(WIFI/3G/4G Optional), Embedded SIM Slot, 1*MINI PCIE Slot(Support MSATA).
There are three different combinations of expansion kits: (Choose 1 from 3)
- 1*PCIE X4 + 1*PCI(32bit),Built-in 1*USB2.0
- 2*PCI(32bit),Built-in 1*USB2.0
- 1*PCIE X4 + 1*PCIE X1,Built-in 1*USB2.0
Additionally, it has 1*MSATA Slot,1*2.5" HDD, and one easy-swappable 2.5" HDD trays for storage.
| Model | IBOX-701 Plus |
| Chassis | Blue + Grey all aluminum Chassis |
| Processor | Intel Celeron 3865U,Intel Core i5 7200U, Intel Core i7 7500U |
| RAM | 1*DDR4 1866/2133 SODIMM RAM Slot,Max 16GB |
| Storage | 1*MSATA Slot,1*2.5" HDD |
| Display Port | 1*VGA,1*HDMI Built-in Pin |
| I/O | 4*USB3.0,2*USB2.0 |
| 1*Clean COMS button,Standard 4*COM(6*COM Optional,COM1,COM2 RS232/422/485 Optional) | |
| 2*Intel 1000M LAN,1*VGA,1*3Pin Power Phoenix Connector | |
| 2*Indicator light,1*Power Switch | |
| Expansion Port | 1*MINI PCIE Slot(WIFI/3G/4G Optional),Embedded SIM Slot |
| 1*MINI PCIE Slot(Support MSATA) | |
| (Choose 1 from 3) | 1*PCIE X4 + 1*PCI(32bit),Built-in 1*USB2.0 |
| 2*PCI(32bit),Built-in 1*USB2.0 | |
| 1*PCIE X4 + 1*PCIE X1,Built-in 1*USB2.0 | |
| Input Voltage | DC 9～36V wide voltage Input |
| Work Temp | 0℃ ～ +50℃,-20℃ ～ +60℃ |
| Work Humidity | 5% ～ 95% non-condensing |
| Dimension | 215 * 185 * 115 mm【Not include the brackets】 |
| Net Weight | 3.6 kg【Not include the brackets】 |
The application-ready IBOX-701Plus Fanless Computer with PCI Slot is in stock. Get more product information or pricing. Welcome to visit our website at www.iwillminipc.com or contact one of our sales representatives at jessie@iwillminipc.
