I5 I7 Fanless Industrial PC

Model

IBOX-3046

Color

Titanium gray (Color can be customized)

Material

Aluminum alloy chassis

Processor

Onboard Intel Celeron 4205U (Dual core dual threads, 1.8Ghz, 2MB Cache)

Onboard Intel Core i5-8265U (Quad core eight threads, 1.6Ghz, Max turbo 3.9Ghz, 6MB Cache)

Onboard Intel Core i7-8565U (Quad core eight threads, 1.8Ghz, Max turbo 4.6Ghz, 8MB Cache)

RAM

Support 1*DDR4 2133/2400 SODIMM Memory slot, Max. Support 32GB

BIOS

AMI EFI BIOS

Display Chip

Integrated Intel UHD Graphics

Display Port

1*VGA, 1*HDMI (Support synchronous and asynchronous dual display)

Front I/O

2*USB2.0, 2*COM, 1*VGA

Rear I/O

4*Intel 1000M LAN, 4*USB3.0, 1*HDMI, 1*Audio (Support Mic and Speaker at the same time)

2*COM (COM1, COM2 RS232/RS422/RS485 Optional), 1*2Pin power supply phoenix connector, 1*Power Switch

Expansion

Support 1*M.2 M-Key 2280 slot (Support SATA Protocol)

Support 1*MINI PCIE Slot (WIFI/3G/4G Optional; choose one from three), embedded SIM Slot

Expansion Ports: GPIO (8 Input 8 Output), 2*COM, 1*USB2.0 (Standard version doesn't include these ports)

Network

4*Intel i211-AT 10/100/1000M LAN

Storage

1*M.2 2280 slot, 1*2.5" HDD, Support RAID 0/1

Input Voltage

DC 9V ～ 36V wide voltage Input, support positive pole and negative electrode connect reversely protection

Other Function

TPM2.0 security encryption, Auto power on when there is electricity, Timing boot, Wake on LAN, PXE boot, Watchdog (0～255 level) (Standard version doesn't set these function)

Work Temp

0℃ ～ +50℃ (Commercial HDD), -20℃ ～ +60℃ (Industrial SSD), Surface air flow

Work Humidity

5% ～ 95% non-condensing

Certificates

CE, CCC, FCC Class A, ROHS

Size

280*143*40mm

Weight

1.45kg

Application

Industrial Automation, Medical, Data Acquisition, Motion Control, Vehicle Applications etc.
