AMD Ryzen Embedded Mini PC For Edge AI
◆ AMD Ryzen R2314: 4-core/4-thread, 2.1GHz / 3.5GHz turbo.
◆ Fanless & Rugged: All-aluminum passive cooling, silent 24/7.
◆ 6x COM Ports: 4x RS232 + 2x RS485 for industrial devices.
◆ Dual 4K HD-MI: Two independent outputs up to 4096x2160@60Hz.
◆ Up to 64GB RAM: 2x DDR4 SODIMM slots for data-heavy tasks.
◆ Wide Voltage: DC 12V-24V input, -20°C to +60°C operation.
◆ Triple Expansion: Mini PCIe (mSATA) + M.2 2230 (Wi-Fi/BT) + M.2 3052 (4G/5G + SIM).
Send Inquiry
Product Details ofAMD Ryzen Embedded Mini PC For Edge AI
Powerful AMD Ryzen Embedded Fanless Mini PC for Advanced Industrial Automation
The Nano-N332F is a rugged, fanless industrial mini PC powered by the AMD Ryzen Embedded R2314 processor. Built with a high-quality all-aluminum alloy chassis, it delivers silent, dust-proof, and maintenance-free 24/7 operation in demanding environments. From factory automation and robotics to machine vision and IoT gateways, the N332F provides the computing power and I/O flexibility required for modern edge applications.
Features of n332F AMD Ryzen Embedded Mini PC for Edge AI
AMD Ryzen Performance – The R2314 processor features 4 cores and 4 threads based on Zen+ architecture, with a base frequency of 2.1GHz and turbo boost up to 3.5GHz. Integrated AMD Radeon Graphics delivers exceptional visual performance for HMI and imaging tasks.
Extensive Serial Connectivity – With 6 independent COM ports (4x RS232, 2x RS485), the N332F connects directly to multiple legacy industrial devices, eliminating the need for external serial adapters or expansion modules.
Dual 4K Displays – Two HD-MI 2.0 ports support synchronous or asynchronous dual displays at up to 4096x2160@60Hz, ideal for digital signage, control room monitors, and medical imaging.
Industrial-Grade Reliability – Wide voltage input (12V-24V DC) and wide temperature operation (-20°C to +60°C with industrial SSD) ensure stable performance in vehicles, outdoor kiosks, and factory floors. Built-in watchdog timer, TPM 2.0, auto power-on, and Wake-on-LAN enhance system reliability.
Basic feature
| Processor | AMD Ryzen™ Embedded R2314 (4core 4-thread, base 2.1 GHz, turbo boost 3.5 GHz) |
| Memory | 2 x DDR4 2400MHz SODIMM memory slots, max 64 GB. |
| Storage | 1 x MINI PCIe (MSATA SSD) slot , 1 x 2.5-inch hard drive bay |
| Architecture | Zen + Micro architecture |
| Display Port | 2*HD |
| USB | 4*USB 2.0, 2*USB 3.2 |
| COM | 6 x COM (COM 1–4 are RS232, COM 5–6 are RS485) |
| Network | 2 x RTL8111H 10/100/1000M Gigabit Ethernet cards |
| Dimension | 186 * 140 * 66 mm |
Ready to power your next industrial project with the Nano-N332F?
Contact our team today for volume pricing, customization requests, or to request a sample unit. Whether you need hardware modifications, BIOS customization, or assistance with integration, we're here to help you succeed.
Get in touch,Let's build something intelligent together.
