Model | N13 |
Color | Black (Color can be customized) |
Material | High-quality all aluminum，surface anodic oxidation |
Processor | Intel Core i3 7100U (dual core quad threading，3MB third level cache，2.4GHz) |
Intel Core i5 7200U (dual core quad threading，3MB third level cache，2.5GHz，Max. turbo 3.1 GHz) | |
CPU Architecture | KabyLake-U |
RAM | Support 2*DDR4 1866/2133 MHz SODIMM RAM Slot，Max. Support 32GB |
Display Chip | Integrated Intel HD Graphics 610/620 |
Display Port | 1*HDMI（NO Sound Output） |
Front I/O | 4*USB3.0，1*Power Switch，1*RJ45 COM（Support Console function）,1*HDMI |
Rear I/O | 6*RJ45 LAN, 1*DC Input |
Expansion Slot | Support 1*MINI PCIE Slot（WIFI/Bluetooth Optional） |
Support 1*MINI PCIE Slot（Support MSATA） | |
Network | 6*Intel 82583V 10/100/1000M LAN |
Storage | 1*MSATA Slot，1*2.5”HDD |
Input Voltage | Support DC 12V Input |
Other Function | Auto power on when there is electricity、Timing boot、Wake on LAN、PXE boot、Watchdog（0～255 level）(Standard version doesn’t set these function) |
