12.1 Inch Industrial Panel PC

This product is a cost-effective 12.1-inch TFT industrial-grade touch panel PC. It offers flexible processor options, including Intel® Celeron® J1900, Intel® Pentium® 3558U, or Intel® Core™ processors, delivering high-performance computing in a compact embedded system. Designed for industrial environments, it features a durable, IP65-rated front panel, supports resistive or capacitive touch, and offers multiple I/O interfaces to meet various industrial application needs.

Key Features
12.1-inch LCD screen with LED backlight (custom sizes available)
IP65-rated front panel for waterproof and dustproof protection
Intel® 4th Gen Pentium 3558U, Fanless design for energy efficiency and silent operation
Touch options: 5-wire resistive touch or 10-point projected capacitive touch
All-aluminum die-cast housing for industrial durability

Embedded IPC Installation Guide

• Confirm the cabinet cutout size, and insert the device into the cabinet.
• After insertion, check for proper spacing around the unit.
• Take out the four included buckle brackets.
• Align each bracket with the mounting holes on both left and right sides.
• Ensure the brackets snap firmly onto the panel as shown in the figure.
• Secure the brackets with a cross screwdriver, applying suitable force.
• Verify all brackets are fastened tightly by gently shaking the panel.
• Confirm the installation effect of the embedded IPC.

Corrected Version:

The A116 model is a 12.1-inch fanless resistive touch panel PC, powered by Intel Whiskey Lake U-series processors. Optional configurations include Intel Celeron J6412, 4205U, and Intel Core i3/i5/i7 processors. The screen brightness reaches up to 350 nits, with a 4:3 aspect ratio and a resolution of 1024 × 768. It features an industrial-grade resistive multi-touch screen with a lifetime of over 50,000 touches. The operating temperature range supports 0℃ to +50℃ (commercial) and -20℃ to +60℃ (with industrial SSD).

12.1-Inch Fanless Resistive Touch Panel PC

The 12.1-inch touch screen panel PC adopts a die-cast aluminum alloy housing and a fanless design. A key feature is the removable memory and hard drive-for replacement, you simply unscrew the designated area, which is convenient for maintenance. TPM 2.0 security encryption is also supported to protect the system.

Customization and Product Range

We offer a variety of sizes from 10-inch to 21.5-inch touch screen panel PCs to meet your customized needs. If you're interested in the 12.1-inch embedded panel PC or any other models, feel free to contact us for consultation.
