Rugged Fanless Industrial Computer I5 7200U IPC

dual lan IPC _01

Specification
Model	IBOX-704 Plus
Color	Blue + Grey (Color can be customized)
Material	High-quality all aluminum, surface anodic oxidation
Processor	Intel Celeron 3865U (Dual core dual threads, 2MB third level cache, 1.8 GHz)
	Intel Core i5 7200U (Dual core quad threads, 3MB third level cache, 2.5GHz, Max turbo 3.1GHz)
	Intel Core i7 7500U (Dual core quad threads, 4MB third level cache, 2.7GHz, Max turbo 3.5GHz)
RAM	Support 1*DDR4 1866/2133 SODIMM RAM Slot, Max. Support 16GB
BIOS	AMI EFI BIOS
Display Chip	Integrated Intel HD Graphics 610/620
Display Port	1VGA, 1HDMI Built-in Pin (Support synchronous and asynchronous dual display)
Front I/O	2USB3.0, 2USB2.0, 1HDD LED, 1Power Switch, 1MIC, 1Speaker
Front I/O	1*Phoenix Connector (can expand out the switch signal)
Rear I/O	2USB3.0, 2Intel 1000M LAN, 1VGA, 13Pin Power Supply Phoenix Connector
Rear I/O	1Clean COMS button, Standard 4COM (6*COM Optional, COM1, COM2 RS232/422/485 Optional)
Expansion Port	Support 1*MINI PCIE Slot (WIFI/3G/4G Optional), Embedded SIM Slot
	Support 1*MINI PCIE Slot (Support MSATA)
	Optional Ports: GPIO, Audio, HDMI, 2*COM (Standard version doesn't include these ports)
Expansion Slot	1PCIE X4 + 3PCI (32bit), Built-in 1*USB2.0, Max. Can support the length of expansion card: 196 mm
Network	2*Intel i211-AT 10/100/1000M LAN
Storage	Support 1MSATA Slot, 1*2.5" HDD
Input Voltage	DC 9～36V wide voltage Input, Support positive pole and negative electrode connect reversely protection
Other Function	Auto power on when there is electricity, Timing boot, Wake on LAN, PXE boot, Watchdog (0～255 level) (Standard version doesn't set these function)
Work Temp	0℃ ～ +50℃ (Commercial HDD), -20℃ ～ +60℃ (Industrial SSD), Surface air flow
Work Humidity	5% ～ 95% non-condensing
Certificates	CE, CCC, FCC Class A, ROHS
Dimension	215 * 185 * 157 mm【Not include the brackets】
Net Weight	4.0 kg【Not include the brackets】
Application	Industrial Automation, Medical, Logistics Transportation, Warehouse, Machine vision, etc.

dual lan IPC _02

dual lan IPC _03_1

dual lan IPC _03_2

dual lan IPC _04

dual lan IPC _05

dual lan IPC _06_1

dual lan IPC _06_2
